Including: U channels, C sections, mild steel channels
Manufactured to the precise sizes and weights below, our PF Channels are suitable for a range of uses in residential and commercial builds. Please get in touch if you need expert help.
PFC sizes and weights
Don’t see the size you need listed below? Contact us for advice.
| Size | Weight | Depth | Width | Web Thickness | Flange Thickness |
|---|---|---|---|---|---|
| (mm) | (kg/m) | (mm) | (mm) | (mm) | (mm) |
| 150×75 | 18 | 150 | 75 | 5.5 | 10.0 |
| 150×90 | 24 | 150 | 90 | 6.5 | 12.0 |
| 180×75 | 20 | 180 | 75 | 6.0 | 10.5 |
| 180×90 | 26 | 180 | 90 | 6.5 | 12.5 |
| 200×75 | 23 | 200 | 75 | 6.0 | 12.5 |
| 200×90 | 30 | 200 | 90 | 7.0 | 14.0 |
| 230×75 | 26 | 230 | 75 | 6.5 | 12.5 |
| 230×90 | 32 | 230 | 90 | 7.5 | 14.0 |
| 260×75 | 28 | 260 | 75 | 7.0 | 12.0 |
| 260×90 | 25 | 260 | 90 | 8.0 | 14.0 |
| 300×90 | 41 | 300 | 90 | 9.0 | 15.5 |
| 300×100 | 46 | 300 | 100 | 9.0 | 16.5 |
| 380×100 | 54 | 380 | 100 | 9.5 | 17.5 |
| 430×100 | 64 | 430 | 100 | 11.0 | 19.0 |
Our Parallel Flange Channels can be used in a wide range of construction services, including small residential properties and large commercial premises. We have a wide variety of sizes available, but if you don’t see what you want you can talk to us about our tailor-made options. This steel beam is sometimes referred to as a C section because of its shape.
PFCs are used for columns and lintels for doors as a support for floors and they are also used for cavity walls which require insulation. They are ideal for awkward spaces which can be found in attics or basement areas.
